Designing a water tank structure is a complex civil engineering task that requires careful consideration of its location, materials, loads, and adherence to established standards like the Indian Standard (IS) code IS-3370. The design must prioritize leak-proofness and structural stability under various conditions, such as hydrostatic pressure, wind, and seismic forces
Water tanks are broadly classified by their position and geometry.
By position
- Overhead tanks: Elevated on supporting structures (staging) to provide water pressure through gravity. These are prominent in Indian homes for everyday water supply. The staging, composed of columns and bracing, must be designed for both the weight of the tank and environmental loads like wind.
- Tanks resting on the ground: Placed directly on the ground at a specific elevation. They are economical as they don’t require elevated staging and are easier to access, making them suitable for agriculture or large-scale storage.
- Underground tanks: Buried below ground level, making them ideal for conserving space in apartment buildings or urban areas. They must be designed to withstand both internal water pressure and external earth pressure, and potentially uplift pressure from groundwater.
By shape
- Circular tanks: More efficient for resisting internal hydrostatic pressure due to their geometry, which develops hoop tension in the walls. They require less material than rectangular tanks for the same capacity and are less prone to leakage at corners.
- Rectangular tanks: Simpler and cheaper to construct due to lower formwork (shuttering) costs. However, they require more material and are more susceptible to leakage at corners.
- Intze tanks: A specialized circular tank design with a dome-shaped roof and conical or spherical bottom, typically used for storing large volumes of water.
Material options
While water tanks can be made from various materials, reinforced concrete cement (RCC) is a common choice, especially for permanent, large-capacity tanks.
- Reinforced Concrete (RCC): Durable and long-lasting, with excellent thermal insulation properties that help maintain water temperature. The concrete mix must be dense and impermeable to prevent leakage. IS 3370 governs the design and detailing of RCC tanks.
- Steel: Offers high strength and durability, particularly in industrial applications. It must be protected with anti-rust coatings to prevent corrosion.
- Plastic (Polyethylene): The most popular option for residential use due to its lightweight nature, affordability, and resistance to corrosion. It is easy to transport and install, and food-grade plastics are available for potable water storage.
Key design considerations
Structural analysis
The tank’s structural components (walls, roof, floor, and foundation) must be analyzed to withstand various loads and ensure watertightness.
- Load types: Internal hydrostatic pressure, external earth pressure (for underground tanks), self-weight, snow loads, wind loads (especially for elevated tanks), and seismic forces.
- Cracking resistance: For RCC tanks, the design must assume the concrete section is uncracked to limit tensile stress and prevent water seepage. The permissible stress in the steel reinforcement is also reduced for components in contact with water.
- Earthquake resistance: Elevated tanks are highly vulnerable to seismic forces due to the large mass concentrated at the top. The design must account for dynamic forces and sloshing effects of the water.
Materials and construction
- Concrete mix: A high-quality concrete mix, generally M20 or higher, is required for water-retaining structures. It must have a low water-cement ratio and be efficiently compacted to reduce permeability.
- Reinforcement: Minimum reinforcement percentages are specified to minimize cracking due to temperature and shrinkage. For sections thicker than 225 mm, two layers of reinforcement should be used.
- Cover to reinforcement: A minimum cover of 25 mm or the diameter of the main bar (whichever is greater) is required for steel on the water-retaining face to protect it from corrosion.
- Joints: Movement joints, such as contraction and expansion joints, are provided to accommodate temperature and shrinkage effects.
Foundation design
The foundation’s type and size depend on the tank’s position and the soil’s bearing capacity.
- Slab foundation: A reinforced concrete slab can be used under the entire tank for ground-level or underground tanks, especially where the soil bearing capacity is low.
- Ring foundation: For large circular tanks, a concrete ring wall is often used beneath the tank walls to distribute the load to the soil.
- Piled foundation: Necessary for tanks built on soft or weak soil.
Design process
- Determine tank capacity and dimensions based on water demand and space constraints.
- Select the tank type and material (e.g., elevated RCC circular tank) based on budget, site conditions, and aesthetic requirements.
- Perform structural analysis for all loading conditions (hydrostatic, wind, seismic, etc.) to determine internal forces (bending moment, hoop tension, etc.).
- Design the structural components (walls, floor, roof, staging) using the working stress method, referencing standards like IS 3370. Ensure reinforcement detailing minimizes cracking.
- Design the foundation based on the total load transferred by the tank and the soil’s bearing capacity.
- Detail the construction joints and other specifics to ensure watertightness.
